The application of ultrasonic processing not only can provide energy for reaction, but also can achieve better mixing and more rapid separation. It will be good using for essential oil extraction handing the Crude Oil 12-16° API
Item No.:
HSS20-3000-IPayment:
T/T, PayPal, WWestern UnionProduct origin:
ChinaColor:
Silver and blueShipping port:
Ningbo and ShanghaiLead Time:
30
Milk with Standard Fitting Using in Pharmaceuticals Industry for Ultrasonic Processor Sonochemistry Equipment
Description:
The goal of homogenization is not only to break apart, but to mix, particles. And in this sense, ultrasonic homogenizers hold an advantage, as their stimulation of cavitation so effectively disrupts molecular bonds that the total particle surface area is greatly increased. This is because breaking apart particles creates more particles with more surfaces. And when there is a greater total surface area and a tighter distribution of particles, there is improved opportunity for particle agglomeration and overall improved stability.
Furthermore, ultrasonic homogenizers have fewer parts to maintain and to clean, and they can be customized according to specific amplitude and pressure ranges, making them great choices for scientists and manufacturers wanting complete control over the cavitation process.
Specification:
Model |
HSS20-500-L |
HSS20-1000-I |
HSS20-1500-I |
HSS20-2000-I |
HSS20-3000-I |
Frequency |
20±1 kHz |
20±1 kHz |
20±1 kHz |
20±1 kHz |
20±1 kHz |
Power |
500 W |
1000 W |
1500 W |
2000 W |
3000 W |
Voltage |
220±10% V |
220±10% V |
220±10% V |
220±10% V |
220±10% V |
Temperature |
150 ℃ |
150 ℃ |
300 ℃ |
300 ℃ |
300 ℃ |
Pressure |
Normal |
Normal |
35 MPa |
35 MPa |
35 MPa |
Intensity of sound |
>10 W/cm² |
>10 W/cm² |
>30 W/cm² |
>40 W/cm² |
>60 W/cm² |
Max Capacity |
> 100M L/Min |
> 5 L/Min |
> 15 L/Min |
> 20 L/Min |
> 30 L/Min |
Material Of Tip Head |
Titanium Alloy |
Titanium Alloy |
Titanium Alloy |
Titanium Alloy |
Titanium Alloy |
Application:
1. Breaking up of cells, bacteria, viruses, spores, fungi, or tissues
2. Extraction of ingredients
3. Homogenization of substances of all kinds
4. Production of the finest emulsions with minimal droplet size
5. Dissolution of hard-to-dissolve and extremely hard-to-dissolve substances in fluids
6. Manufacture of dispersions and suspensions
7. Catalysis and acceleration of chemical reactions
Characteristic:
1. Ultrasound probe is imported titanium alloy material, durable
2. Energy-efficient transducer to ensure a strong effect
3. Amplitude automatic adjustment, the load situation of the different amplitude consistent
4. Working hours, ultrasound can set the interval
5. Microcomputer control, ultrasonic power continuously adjustable
6. Integrated sample temperature control to prevent overheating
7. Speakers are separated by a special sound insulation, sound insulation
